Description
Features
- Rest areas
- Stadiums
- Schools
- Restaurants
- Hotels
- Public amenities
Features
- Compact solid design
- Commercial grade quality and fully backed by our industrial warranty
- Single temperature
- Double infrared sensor with automatic setting feature and microprocessor
- Bi-stable magnetic solenoid valve (for increased energy savings)
- Water supply connection with flexible high-pressure hose and strainer
- 6V lithium CR-P2 commercial battery included / 240V
- Iqua touch feature enables temporary – off (for cleaning purposes) or continuous water flows (for filling the basin)
- Appropriate mounting hardware included
- Check valve and built-in strainer
- 12, 24 or 72-hour hygienic rinse activatable
- Installation similar to conventional single-lever tap
Technical Information
- Operating pressure: 30kPa – 500kPa
- Maximum water temperature: 80°C
- Aerator: Economy aerator, cascade (self-cleaning)
- Inlet Connection: Flexible hose at 350mm long
- Strainer: 0.5mm mesh size
- Sensor-sensitivity: Automatic self-adapting sensor technology
- Sensor range nominal: 102mm – 127mm
- Hygienic rinse time: 2 minutes pre-set (adjustable from 0.5 – 20 minutes)
- Temporary-off: 2 minutes (fixed)
- Time Out Setting: 2 minutes — Maximum time tap will run upon continuous detection
- Engineering standards: Noise class I, DIN EN 200; P-IX 9576 / IA
